Model No.︰12
Brand Name︰LINGYUN
Country of Origin︰China
Unit Price︰US $ 650 / MT
Minimum Order︰1 MT
Share on:

 Total 20 Related Items
Prev1617181920

Product Description

[Application]:
The product is made from ordinary carbon structured or high quanlity carbon strctured steels via cold-rolled,eletric heat and blue and paintbaked.It is applicable for bundling and packing of wood,paper,cotton spinning,glass,
Stone,steels,weld tube and so on large objects.

[Sort of steel packing strips]:
(1) White steel packing strips
(2) Blue steel packing strips
(3) Paintbaked steel packing strips(black,green,gray,yellow etc.)

[Mechanical properties]:
(1)Ordinary steel strips(Ⅰ):
tensile strengthσb≥58-78Kg/mm2(580-780Mpa),elongation
3%-5%
(2)Ordinary steel strips(Ⅱ):
tensile strengthσb≥78-90Kg/mm2(780-900Mpa),elongation
3%-5%
(3)High quality steel strips:
high high intesity,good capability,bearing impact.tensile strength: 90-100Kg/mm2 (900-1000Mpa) , elongation
5%-10%

[Specification]:
BWG28×3/8″
1/2″5/8″0.36mm×9.5mm12.7mm16mm
BWG27×3/8″
1/2″5/8″0.40mm×9.5mm12.7mm16mm
BWG26×1/2″
5/8″3/4″0.45mm×12.7mm16mm19mm
BWG25×1/2″
5/8″3/4″0.50mm×12.7mm16mm19mm
BWG24×1/2″
5/8″3/4″0.55mm×12.7mm16mm19mm
BWG23×1/2″
5/8″3/4″0.60mm×12.7mm16mm19mm
BWG22×3/4″
1″5/4″0.70mm×19mm25.4mm32mm
BWG21×3/4″
1″5/4″0.80mm×19mm25.4mm32mm
BWG20×3/4″
1″5/4″0.90mm×19mm25.4mm32mm
BWG19×3/4″
1″5/4″1.0mm×19mm25.4mm32mm

[Others]:
We can produce special specification as per customers request,and we can make the edge smoother of the steel packing strips.

Payment Terms︰T/T
